Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards

Certification
China Shenzhen jianhe Smartcard Technology Co.,Ltd certification
China Shenzhen jianhe Smartcard Technology Co.,Ltd certification
I'm Online Chat Now

Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards

Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards
Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards

Large Image :  Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards

Product Details:
Place of Origin: Shenzhen,China
Brand Name: JH
Certification: CE,RHOS,SGS
Model Number: EM 4450 / 4550 card
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: 200 PSC / box
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 10,000,000 pcs per month

Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards

Description
Material: PVC, PET, ABS Etc. Thickness: 0.84 Mm
Chip: EM 4450 / 4550(EM-marine) Frequency: 125 KHz
Surface: Matte/Glossy/frosted Protocol: ISO 18000-2
Memory: 1K Bit Application: Ticketing,Automotive Immobilizer With Rolling Code
High Light:

EM4550 RFID Smart Cards

,

1K Bit RFID Smart Cards

,

EM4450 RFID Cards

Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards



Description

EM4450/4550 is very mature, simple and widely used RFID technology. The chip we embed in the card is original from EM Microelectronic.

The difference between EM4450 and EM4550 is that EM4550 are bumped and has megapads for the two coils. The chip contains 1 KBit of EEPROM which can be configured by the user, allowing a write inhibited area, a read protected area, and a read area output continuously at power on. The memory can be secured by using the 32 bit password for all write and read protected operations. The password can be updated, but never read. The fixed code serial number and device identification are laser programmed making every chip unique.It is widely used in ticketing,automotive immobilizer with rolling code,high security hands free access control,prepayment devices etc.



Card Features

  • IC Manufacturer: EM Microelectronic

  • Chip:EM4450/ 4550

  • Working Frequency:125KHz

  • Dimensions: 85.6 x 54mm (CR80)

  • Thickness: 0.84~0.86mm

  • Material: PVC, PET,  ABS etc for optional

  • Surface: Matte/Glossy/frosted

  • Reading disdance: 6CM typically

  • RF Protocol: ISO 18000-2

  • Housing: Lamination



Chip Features

  • 1 KBit of EEPROM organized in 32 words of 32 bits

  • 32 bit Device Serial Number (Read Only Laser ROM)

  • 32 bit Device Identification (Read Only Laser ROM)

  • Power-On-Reset sequence

  • Power Check for EEPROM write operation

  • User defined Read Memory Area at Power On

  • User defined Write Inhibited Memory Area

  • User defined Read Protected Memory Area

  • Data Transmission performed by Amplitude Modulation

  • Two Data Rate Options 2 KBd (Opt64) or 4 KBd (Opt32)

  • Bit Period = 64 or 32 periods of field frequency

  • 170 pF ± 2% on chip Resonant Capacitor

  • -40 to +85°C Temperature range

  • 100 to 150 kHz Field Frequency range

  • On chip Rectifier and Voltage Limiter

  • No external supply buffer capacitance needed due to low power consumption

  • Available in chip form for mass production and PCB and CID package for samples.



Available crafts

  • Full color offset printing,Silk-screen printing,Silver/Gold silk-screen printing background

  • Magnetic stripe (LoCo300,HiCo2750/4000,Magstripe encoding)

  • Signature panel or Scratch off panel

  • Print of Serial Number, UID, Barcode(Jet dot/ Thermo transfer/ Laser engrave,Embossing)

  • Print of Personalization: Name/Photo

  • Hot Foil, Hologram

  • Special colors: Silver/Gold/Metallic colors

  • Special overlay: UV/EVC

  • Punch Hole



Application

1. Ticketing
2. Automotive Immobilizer with rolling code
3. Access Control
4. Industrial automation with portable database
5. Manufacturing automation
6. Prepayment Devices



Package



To make sure cards can be delivered without any damage,we provide the most solid and the safest packaging.

Contactless EM4450 4550 Chip 1K Bit RFID Smart Cards 0



Dimensions of the inner box:



Description

Size

Quanlity

Inner box

215*100*62 mm

200 pcs



Dimensions of the Outer Carton:



Description

Size

Quanlity

Net weight

Gross weight

Outer Carton

245*215*190 mm

1000 pcs

6.00 kgs

6.80 kgs

Outer Carton

520*225*145 mm

2000 pcs

13.00 kgs

13.60 kgs

Outer Carton

520*225*260 mm

4000 pcs

26.00 kgs

28.00 kgs

Outer Carton

520*225*325 mm

5000 pcs

32.00 kgs

34.00 kgs
