Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels

Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels
Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels

Large Image :  Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels

Product Details:
Place of Origin: Shenzhen,China
Brand Name: JH
Certification: CE,RHOS,SGS
Model Number: Windshield label-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: 5000 pcs /roll
Delivery Time: 5-8work days
Payment Terms: T/T in Advance,PayPal,Credit Card
Supply Ability: 10,000,000 per month

Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels

Description
Type: Windshield Label Material: Paper
IC Type: Higgs3, G2XM Printing: CMYK Offset Printing, Silkscreen Printing Etc.
Frequency: 860-960 Mhz Applications: Automatic Vehicle Identification
High Light:

Higgs3 RFID Tags Labels

,

Higgs3 Windshield label

,

G2XM Windshield label

Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels



RFID windshield tags with logo printing for automatic vehicle identification



Description

Customized Windshield Tags offer a more accurate and secure way to allow access into various locations like a gated community, company/corporate secured parking, or even a car wash. The inlay utilizes passive technology and is encapsulated between thin layers of polypropylene adding human readable printing to one side and a windshield-compatible adhesive to the other. Unlike other windshield tags on the market, the RFID Windshield Tag utilizes passive RFID UHF technology offering a more economical option to the active windshield tags available. Encased between thin layers of polyester, the specialized inlay doesn’t require a standoff to read either through or on a glass windshield. A tamper-evident option with strategically placed slits in the label and adhesive layers is also available at no additional cost.

Specialty RFID labels take advantage of sub-surface printing wherein the printed media has a protective covering. In order to remove the copy from a label, one would have to destroy the label itself.

Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels 0



Features

  • Specialized inlays read well through windshield glass.
  • Read ranges of 18+ feet*.
  • Unlimited color options with choice of up to four standard or custom colors.
  • High frequency (HF) available
  • Double-sided registered option available (pricing available upon request).
  • Detailed printing process provides for great printing capabilities with detailed logos or specialized designs.
  • Destructible option prevents unauthorized vehicles from using tags transferred from authorized vehicles.



Specifications

  • Product Name: RFID Windshield Tag
  • Material: Antenna: Aluminum etched

                         Substrate: paper

                         Coating: breakable paper & release paper, adhesive layer

  • Frequency: 902-927MHz(ISO18000-6C)
  • Chip: Higgs3, G2XM
  • Dimension: 106 *28 mm
  • Working Mode: Passive
  •  Working Temperature: 0~40℃
  • Printing: Offset Printing
  • Humidity: 60%~90%
  • Weight: 4.80±0.05g



Application

A wide selection of automatic vehicle identification applications such as access control, parking permit, road toll collection or insurance information verification, vehicle and traffic management.

The windshield tag help to realize automatic checking and charging, which greatly saves time of drivers, avoid long time waiting in toll station or parking entrance. At the same time, the replacement of labors improves work efficiency, and avoid manual mistake.

Vehicle Identification Higgs3 G2XM Windshield RFID Tags Labels 1



Our Services

1. Warranty: 1 years
2. Free Replacement: If have inaccurate card within order, Jianhe Smart Card will provide free replacements.


Our Advantage:

1. PVC material is safety and environmental protection
2. Best printing machine: Germany Heidelberg four-color printer, exquisite printing quality.
3. Anti scratch, more durable with overlay and protect film.



FAQ
Q: Are you a manufacturer or trading company?
A: We are manufacturer with a history of 16 years.

Q: Could you write my company website in the tag?
A: Yes. Tap your tag and link to your company website.

Q: Will the encoding/programming be done by ourselves or by your company?
A: The tags/cards can be blank for being encoded by you. They can be preprogrammed if necessary.

Q: Could I get the free sample for testing?
A: Yes, in order to show our sincerity, we could offer you free sample for testing to support you.

Q: Do you also supply OEM service?
A: Yes, Since we keep professional manufactory with own moulding line and product line, so we could help to print LOGO on the products to make them unique.

Q: How do you control the quality?
A: Quality is priority, is the life of our company. We have a strict quality controlling system and has gained CE authentication.

Q: How can we get free samples from yours
A: We respect everyone of our customers and can contact or mail to us for RFID Sticker Tag sample testing request , normally 2-4 pcs for testing .
